「快速門電控箱」堆積門變頻控制箱的技術特點

「快速門電控箱」堆積門變頻控制箱的技術特點


The Technical Characteristics of "Fast Gate Electronic Control Box" Stacking Gate Frequency Converter Control Box


變頻柜，普通的動力柜或控制柜由傳統拖動方式改為變頻拖動方式。簡而言之：應用變頻器拖動動力裝置的控制柜。


Frequency conversion cabinet, ordinary power cabinet or control cabinet is changed from traditional drive mode to frequency conversion drive mode. In short: the application of frequency converter to drive the control cabinet of power plant.


因其良好的啟動性能、調速性能和節能效果而成為當前推廣的動力拖動方式。


Because of its good start-up performance, speed regulation performance and energy-saving effect, it has become the current promotion of power drive mode.

「快速門電控箱」性能穩定可靠，抗干擾性好：PLC應用于各種工業控制現場，其硬件及軟件設計均考慮到各種生產環境，其電壓適用范圍很寬，具有極強的抗電磁干擾、抗震動、抗高溫、高濕等特性，性能極為穩定、可靠。


"Fast Gate Electronic Control Box" has stable and reliable performance and good anti-interference: PLC is used in various industrial control sites, its hardware and software design takes into account various production environments, its voltage range is wide, with strong anti-electromagnetic interference, anti-vibration, high temperature, high humidity and other characteristics, the performance is extremely stable and reliable.


PLC自動化控制系統應用在冷凍干燥機上可以完成智能控制、狀態顯示和故障報警等任務，同時還提供良好的人機界面與操作員進行交互，使得修改各種參數簡單、易行，對于機械設備的運行能及時、快速、準確的反映


The application of PLC automation control system in freeze dryer can accomplish the tasks of intelligent control, status display and fault alarm. It also provides a good man-machine interface to interact with operators, which makes the modification of various parameters simple and easy, and reflects the operation performance of mechanical equipment in a timely, fast and accurate manner.



「快速門電控箱」堆積門變頻控制箱的技術特點


The Technical Characteristics of "Fast Gate Electronic Control Box" Stacking Gate Frequency Converter Control Box


一、技術特點


I. Technical Characteristics


1、高度的集成功能


1. High Integration Function


把所有的功能集成化，減少了傳統門機使用的變頻器+PLC的控制方式，只使用變頻器可以滿足所有的功能。


The integration of all functions reduces the control mode of frequency converter + PLC used in traditional portal crane, and only using frequency converter can satisfy all functions.



2、節能成本


2. Energy-saving Cost


減少PLC及相關配件，使控制箱的體積減小，節約成本。


Reduce PLC and related accessories, reduce the volume of the control box, save costs


3、簡化門機控制系統，提高系統安全性。


3. Simplify the door crane control system and improve the system security.


省去了傳統快速門機控制系統中PLC控制的中間環節，提高系統安全性。


The intermediate link of PLC control in the traditional fast door crane control system is omitted and the system security is improved.


4、高性能控制


4. High Performance Control


起動力矩大、運行平穩、高效。


Large starting moment, smooth operation and high efficiency.


實時檢測輸出力矩，受阻力矩可靈活設置。


The output torque can be detected in real time, and the resistance moment can be flexibly set.


零速保持力矩輸出，保證開關門到位的保持力矩。


Zero speed to maintain the torque output, to ensure that the switch door in place to maintain the torque.


5、控制方式


5. Control Mode


支持地磁控制、雷達控制、光電、氣囊等設置


Support geomagnetic control, radar control, optoelectronic, airbag and other settings


6、輸入輸出端子


6. Input and output terminals


專用化的門機輸入輸出端子設計，接線方便


Specialized portal crane input and output terminal design, easy wiring

二、變頻器性能說明


2. Performance description of frequency converter


1、CPU采用美國TI公司的32位級DSP控制器，使性能更完美；


1. CPU adopts 32-bit DSP controller of TI Company of America, which makes the performance more perfect.


2、IGBT使用美國仙童公司生產的模塊，保證產品更高效；


2. IGBT uses modules produced by American Fairchild Company to ensure more efficient products.


3、電容采用日本尼吉康的產品，保證產品的使用壽命更久；


3. Capacitors adopt Nijikang's products to ensure longer service life.


4、其它主要器件全部用進口器件，保證產品的性能更穩定；


4. All other major devices are imported devices to ensure more stable performance of products.


5、SMT表貼工藝，結構緊湊，可靠性強；


5. SMT surface mounting technology, compact structure, strong reliability;


6、按鍵操作，中文液晶顯示，人機界面友好、可操作性強；


6. Keyboard operation, Chinese LCD display, friendly man-machine interface, strong operability;

訂購「快速門電控箱」歡迎聯系我們的客服人員，我們提供全國配送上門，免費指導安裝服務。


Ordering "Fast Gate Electronic Control Box" welcome to contact our customer service personnel, we provide nationwide distribution door-to-door, free guidance and installation services.
